#include <io.h>
#include <stdarg.h>
#include <stdbool.h>
#include <stddef.h>
#include <stdint.h>
#include <types.h>
#include <common.h>
#include <log.h>
#include <reg-dma.h>
#include <sys-clk.h>

Include dependency graph for sys-dma.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
struct	sunxi_dma_desc_t

struct	sunxi_dma_channel_config_t

struct	sunxi_dma_set_t

struct	sunxi_dma_irq_handler_t

struct	sunxi_dma_channel_reg_t

struct	sunxi_dma_reg_t

struct	sunxi_dma_source_t

struct	sunxi_dma_t

Macros
#define	DMA_DEFAULT_CLK_RST_OFFSET (16)

#define	DMA_DEFAULT_CLK_GATE_OFFSET (0)

Functions
void	sunxi_dma_init (sunxi_dma_t *dma)
	Initialize the DMA subsystem.

void	sunxi_dma_exit (sunxi_dma_t *dma)
	Clean up and exit the DMA subsystem.

uint32_t	sunxi_dma_request (uint32_t dmatype)
	Request a DMA channel of the specified type.

uint32_t	sunxi_dma_request_from_last (uint32_t dmatype)
	Request a DMA channel from the last allocated channel of the specified type.

int	sunxi_dma_release (uint32_t dma_fd)
	Release a previously requested DMA channel.

int	sunxi_dma_setting (uint32_t dma_fd, sunxi_dma_set_t *cfg)
	Configure the settings of a DMA channel.

int	sunxi_dma_start (uint32_t dma_fd, uint32_t saddr, uint32_t daddr, uint32_t bytes)
	Start a DMA transfer.

int	sunxi_dma_stop (uint32_t dma_fd)
	Stop a currently running DMA transfer.

int	sunxi_dma_querystatus (uint32_t dma_fd)
	Query the status of a DMA transfer.

int	sunxi_dma_install_int (uint32_t dma_fd, void *p)
	Installs an interrupt handler for the DMA.

int	sunxi_dma_enable_int (uint32_t dma_fd)
	Enables interrupts for the specified DMA.

int	sunxi_dma_disable_int (uint32_t dma_fd)
	Disables interrupts for the specified DMA.

int	sunxi_dma_free_int (uint32_t dma_fd)
	Frees the interrupt resources for the specified DMA.

int	sunxi_dma_test (uint32_t src_addr, uint32_t dst_addr, uint32_t len)
	Perform a test DMA transfer between the specified source and destination addresses.

Macro Definition Documentation

◆ DMA_DEFAULT_CLK_GATE_OFFSET

#define DMA_DEFAULT_CLK_GATE_OFFSET (0)

◆ DMA_DEFAULT_CLK_RST_OFFSET

#define DMA_DEFAULT_CLK_RST_OFFSET (16)

Function Documentation

◆ sunxi_dma_disable_int()

int sunxi_dma_disable_int ( uint32_t dma_fd )

Disables interrupts for the specified DMA.

This function disables the interrupt generation for the specified DMA device, stopping it from signaling interrupts for completed or erroneous DMA operations.

Parameters

dma_fd File descriptor for the DMA device.

Returns: 0 on success, or a negative error code on failure.

Disables interrupts for the specified DMA.

Disables interrupts for a specific DMA channel.

Parameters

dma_fd Handle to the DMA channel

Returns: 0 on success, -1 if channel is not in use

◆ sunxi_dma_enable_int()

int sunxi_dma_enable_int ( uint32_t dma_fd )

Enables interrupts for the specified DMA.

This function enables the interrupt generation for the specified DMA device, allowing it to signal when DMA operations are complete or have encountered errors.

Parameters

dma_fd File descriptor for the DMA device.

Returns: 0 on success, or a negative error code on failure.

Enables interrupts for the specified DMA.

Enables interrupts for a specific DMA channel, specifically package end interrupts.

Parameters

dma_fd Handle to the DMA channel

Returns: 0 on success, -1 if channel is not in use

◆ sunxi_dma_exit()

void sunxi_dma_exit ( sunxi_dma_t * dma )

Clean up and exit the DMA subsystem.

Releases all DMA channels, disables interrupts, and shuts down the DMA controller.

Parameters

dma	Pointer to DMA configuration structure

◆ sunxi_dma_free_int()

int sunxi_dma_free_int ( uint32_t dma_fd )

Frees the interrupt resources for the specified DMA.

This function releases any resources associated with the DMA interrupt handler that was previously installed. It should be called when the DMA is no longer in use.

Parameters

dma_fd File descriptor for the DMA device.

Returns: 0 on success, or a negative error code on failure.

Frees the interrupt resources for the specified DMA.

Releases the interrupt handler associated with a DMA channel and clears pending interrupts.

Parameters

dma_fd Handle to the DMA channel

Returns: 0 on success, -1 if channel is not in use or interrupt handler was not set

◆ sunxi_dma_init()

void sunxi_dma_init ( sunxi_dma_t * dma )

Initialize the DMA subsystem.

Initializes the DMA controller by setting up registers, clearing interrupts, configuring auto clock gating, and initializing channel structures.

Parameters

dma	Pointer to DMA configuration structure containing base addresses and settings

◆ sunxi_dma_install_int()

int sunxi_dma_install_int	(	uint32_t	dma_fd,
		void *	p
	)

Installs an interrupt handler for the DMA.

This function installs a DMA interrupt handler to manage DMA transfer completion or error events.

Parameters

dma_fd	File descriptor for the DMA device.
p	Pointer to the data structure that holds the interrupt handler context or configuration.

Returns: 0 on success, or a negative error code on failure.

Installs an interrupt handler for the DMA.

Sets up an interrupt handler for a DMA channel and clears any pending interrupts.

Parameters

dma_fd	Handle to the DMA channel
p	User data to associate with the interrupt handler

Returns: 0 on success, -1 if channel is not in use

◆ sunxi_dma_querystatus()

int sunxi_dma_querystatus ( uint32_t dma_fd )

Query the status of a DMA transfer.

Parameters

hdma	The DMA channel number to query status for.

Returns: The status of the DMA transfer.

Query the status of a DMA transfer.

Checks whether a DMA transfer is still in progress on the specified channel.

Parameters

dma_fd Handle to the DMA channel to query

Returns: 1 if transfer is in progress, 0 if completed, -1 if channel is not in use

◆ sunxi_dma_release()

int sunxi_dma_release ( uint32_t dma_fd )

Release a previously requested DMA channel.

Parameters

hdma	The DMA channel number to release.

Returns: 0 if successful, or an error code if failed.

Release a previously requested DMA channel.

Releases a previously requested DMA channel, disabling its interrupts.

Parameters

dma_fd Handle to the DMA channel to release

Returns: 0 on success, -1 if the channel was not in use

◆ sunxi_dma_request()

uint32_t sunxi_dma_request ( uint32_t dmatype )

Request a DMA channel of the specified type.

Parameters

dmatype The type of DMA channel to request.

Returns: The DMA channel number if successful, or an error code if failed.

Request a DMA channel of the specified type.

Searches for an available DMA channel starting from channel 0.

Parameters

dmatype Type of DMA channel to request (currently unused)

Returns: Handle to the requested DMA channel, or 0 if no channels are available

◆ sunxi_dma_request_from_last()

uint32_t sunxi_dma_request_from_last ( uint32_t dmatype )

Request a DMA channel from the last allocated channel of the specified type.

Parameters

dmatype The type of DMA channel to request.

Returns: The DMA channel number if successful, or an error code if failed.

Request a DMA channel from the last allocated channel of the specified type.

Searches for an available DMA channel starting from the highest-numbered channel.

Parameters

dmatype Type of DMA channel to request (currently unused)

Returns: Handle to the requested DMA channel, or 0 if no channels are available

◆ sunxi_dma_setting()

int sunxi_dma_setting	(	uint32_t	dma_fd,
		sunxi_dma_set_t *	cfg
	)

Configure the settings of a DMA channel.

Parameters

hdma	The DMA channel number to configure.
cfg	Pointer to the DMA configuration structure.

Returns: 0 if successful, or an error code if failed.

Configure the settings of a DMA channel.

Sets up a DMA channel with specified configuration parameters like loop mode, wait cycles, and data block size.

Parameters

dma_fd	Handle to the DMA channel to configure
cfg	Pointer to configuration structure containing DMA settings

Returns: 0 on success, -1 if the channel is not in use

◆ sunxi_dma_start()

int sunxi_dma_start	(	uint32_t	dma_fd,
		uint32_t	saddr,
		uint32_t	daddr,
		uint32_t	bytes
	)

Start a DMA transfer.

Parameters

hdma	The DMA channel number to start the transfer on.
saddr	Source address of the data to transfer.
daddr	Destination address to transfer the data to.
bytes	Number of bytes to transfer.

Returns: 0 if successful, or an error code if failed.

Initiates a DMA data transfer from source to destination address with specified size.

Parameters

dma_fd	Handle to the DMA channel to use
saddr	Source address for the DMA transfer
daddr	Destination address for the DMA transfer
bytes	Number of bytes to transfer

Returns: 0 on success, -1 if the channel is not in use

◆ sunxi_dma_stop()

int sunxi_dma_stop ( uint32_t dma_fd )

Stop a currently running DMA transfer.

Parameters

hdma	The DMA channel number to stop the transfer on.

Returns: 0 if successful, or an error code if failed.

Stop a currently running DMA transfer.

Halts an ongoing DMA transfer on the specified channel.

Parameters

dma_fd Handle to the DMA channel to stop

Returns: 0 on success, -1 if the channel is not in use

◆ sunxi_dma_test()

int sunxi_dma_test	(	uint32_t *	src_addr,
		uint32_t *	dst_addr,
		uint32_t	len
	)

Perform a test DMA transfer between the specified source and destination addresses.

Parameters

src_addr	Pointer to the source address.
dst_addr	Pointer to the destination address.

Returns: 0 if successful, or an error code if failed.

Perform a test DMA transfer between the specified source and destination addresses.

Performs a DMA transfer test between two memory regions, verifies data integrity, and reports transfer performance.

Parameters

src_addr	Source memory address for test transfer
dst_addr	Destination memory address for test transfer
len	Length of data to transfer in bytes

Returns: 0 on success, -1 if channel request failed, -2 if transfer timed out
